DASH, WIRING AND GAUGE INSTALLATION SUPPORT

Below find dash installation guides, wiring diagrams and harness instructions, and gauge information for your Classic Dash product.  Click here for our FAQs.

TOOLS



Before embarking on the installation, we recommend rounding up the following tools and supplies:



  • Side cutter or “dykes” pliers
  • Soldering iron with solder (or “red” butt connectors)
  • Electrical/crimping pliers
  • Multi-meter (voltage tester)
  • Drill
  • 5/32″ drill bit
  • Crazy glue
  • Center punch or ice pick
  • Tape measure
  • Screwdrivers (Phillips & blade type)
  • Razor blade or box cutter
  • Hand files (fine and medium)
  • Open end wrench or socket set (3/8″ through 9/16″)
  • Shrink wrap with heating device or electrical tape for connections

INSTALLATION VIDEOS

What’s the difference between an electrical and mechanical speedometer?



AutoMeter Garage Episode 12 Chrono Gauge and Classic Dash Panel Install on a ’67 Chevelle SS
